Casita® 10 ft. Heavy Duty Aluminum Canopy Tent (Graphic Package)

7 orders
  • Product Code: canopy-wd-CAL-DLX-10UV
  • Availability: In Stock, printing 3 - 4 days

  • 2 or more $1,035.91
  • 5 or more $1,014.77
  • 10 or more $993.63
  • 25 or more $977.77

Available Options

  • Categories: pop up, canopy, casita,
  • Tag: canopy tent 10x10, heavy duty aluminum tent

10ft Casita Deluxe Pop-Up Canopy Tent for Outdoor Advertising Events, Dye Sub Printing Process with Aluminum Frame

This heavy-duty canopy tent is our toughest tent yet; thick aluminum construction makes it extra sturdy and the most durable. Pop-up canopy tents are an excellent way to advertise your business while protecting you from the elements at outdoor events. This is a standard 10 ft. x 10 ft. size with five different heights, the telescopic legs easily snap into place. The legs on the heavy duty model have a dense 48mm thick girth. The springs inside the frame add tension to the graphic for a perfect fit and form. The graphic is printed on special water resistant material with a UV-cured printing process that dries immediately even in the worst rain storms. The printing on this heavy duty aluminum pop up canopy tent has shiny vivid colors for a professional look that attracts shoppers to your booth. A handy travel bag is included.


Wind Speed Rating: The wind speed rating is 20-28 mph.

*** WARRANTY  Lifetime on Frame, 1 Year on Graphics

Features and Benefits:

  • The aluminum frame on this heavy-duty canopy tent makes it our sturdiest and most durable tent
  • Promote you business while offering protection from the sun, rain or wind!
  • Water resistant material with Dye Sub printing process
  • Pop-up canopy tents are portable and quick and easy to set up in under 10 minutes!
  • Includes a travel bag

Kit Includes:

  • (1) Custom Canopy Graphic
  • (1) Heavy Duty Aluminum Frame
  • (1) Black nylon carry bag
  • (4) Bungees
  • (4) Stakes

Pop-Up Canopy Tent Options:

  • Back-walls: (118.75" w x 88 " h) - requires 1 rail per backwall. These can be single-sided or double-sided. They are fastened to the top of the canopy tent with hook and loop tape and secured at the bottom with a horizontal pole which spans the width of the backwall pole pocket and attach to the legs of the canopy frame. Backwalls can be assembled onto any side of the canopy.
  • Sidewalls: (112”W x 47.5”H) - requires 2 rails per side rail (top and bottom) These can be single-sided or double-sided. They are fastened at the top and at the bottom with a horizontal pole which spans the width of the sidewall pole pockets then attach to the legs of the canopy frame. Sidewalls can be assembled onto any side of the canopy.
  • Cases and bags: The 10ft UV Canopy comes standard with a black nylon bag which has a strap for carrying over the shoulder. An upgrade to our Casita Canopy bag with wheels allows easier transport where longer transport is required by foot, and an upgrade to our La Caja hard case with wheels is designed for shipping offers more protection with a solid, molded plastic construction.
  • Sandbag Cover: This black nylon sand bag cover is used to protect your sand bag as well as to easily attach your sand bag to one leg of the Casita Canopy for added weight against wind. Included is the cover and hook. Do not fill this cover with sand. To use, slip hook through the grommet located on the handle of the cover and then close hook around leg of casita canopy. With the cover already on the ground, open hook and loop tape opening and place sand bag* inside the cover. Close hook and loop tape opening, and you're done.

Graphic Design Services: Available upon request.

Setting up art files How to setup your graphics


  • 10ft x 10ft Canopy, 118.75”W x 135”H x 118.75”D
  • Aluminum frame, heavy duty hex leg thickness 48mm
  • Min. height 100”H, Max. height 142”H
  • Lowest setting to peak 120.25"
  • Graphic canopy size 120”W x 87.25”H
  • Graphic material UV Fabric (water resistant)
  • Back wall: 118.75”W x 88”H
  • Half wall: 112”W x 47.5”H
  • Shipping Dimensions: s 63”L x 13”W x 13”H (over size)
  • Shipping Weight: 75 lbs (Includes frame, canopy and bag)

Graphic Specifications:

  • Finished graphic size 120"w x 87.25"h
  • For exact dimensions, please refer to template below
  • Hemmed around side and bottom edges
  • Un-printed areas will be white

Downloads: Outdoor Popup Canopy UV

NOTE: To download files, click the links below or Right Mouse Click and choose "Save Target As..."
Artwork Template Artwork Template for Custom Printed Canopy Top
Artwork Template Artwork Template for Canopy Tent Backwall
Specifications Printable Spec Sheet for Casita Popup Canopy Tent
Setup Instructions Setup Instructions for Casita Popup Canopy Tent
Artwork Template for Table Throws Throw Templates: 6ft 3-sides | 6ft 4-sides | 8ft 3-sides | 8ft 4-sides
